8-Channel Amplifier with DSP
The Stealth Acoustics 8400 is an integrated eight-channel amplifier / speaker optimization system designed as a low distortion power source for Stealth Acoustics wall or ceiling mounted, invisible speaker panels or other unpowered speakers. Intended for whole house audio or home theater amplification applications, the 8400 may stack with other components or mount in a standard 19” (482 mm) equipment rack requiring only two RU spaces- 3-1/2” (89 mm). Removable rack mount ears are provided.
The 8400 delivers 80 watts per channel into an 8Ω load and adjacent channels are bridgeable to create a 160W output. A DSP-based equalizer section offers pre-defined EQ settings for optimizing all Stealth speakers. With a full complement of input connectors, the 8400 is easily integrated into any audio system. Inputs include assignable RCA line level inputs per channel and a zone “buss” input, allowing for connection to individual channels, bridged channels or a single stereo buss source. The 8400 amplifier output connection is via detachable phoenix-style connectors designed to accept heavy gauge speaker wires. A selectable automatic turn-on feature activates the amplifier only when audio signals are present.
Other features include an internal, quiet, multi-stage cooling fan that automatically engages as required. Front panel controls include a unique data-wheel parameter selection device for user setup, volume control, tone control, bridging, muting, optimization and input assignments. LED indicators are provided on each channel for signal presence and clip as well as to indicate channel status. IR control and a handheld IR remote control are standard features. 110VAC and 220VAC input line voltages are selectable, via a rear panel switch.
The Stealth Acoustics 8400 subwoofer amplifier is covered by a 2-Year manufacturer's warranty.
| Specification Sheet | Download PDF |
|---|
Rack Mountable
(2) RU spaces: 3-1/2” (89 mm)
(Provided rack ears are removed)
DC Protected
Fixed high pass filter @ 18Hz
Power LED
Blue when system is active
Auto On/Standby Function
Saves power by turning off displays, LEDs, and other nonessential functions.
Inputs
RCA assignable Line Level Left / Right Inputs per channel
RCA Line Level Left / Right Buss Inputs (assignable per channel)
Amplifier Output Connector
Removable Phoenix-type connector
Front Panel LED’s
Signal, clip, bridged, optimizations, selected channel and mute (each channel)
Display Window
Main parameter display via easy-to-read back-lit display
Fan Cooled
Automatic, multi-stage
110v and 220v Input Voltages
Mono Power Output
80 watts @ 8 < 0.05 THD
160 watts @ 4 < 0.05 THD (bridged)
Total Harmonic Distortion
<0.05 @ 1 watt 4 / 100Hz
Signal to Noise Ratio
86 dB below rated output
EQ Section
Pre-defined curves for Stealth Acoustics LR3, LR8, LR6 and SLR8 invisible speakers
High-pass filter (subwoofer) along with treble and bass on each channel
System Impedance
8 nominal - 4 minimum
Current Draw
12A @ full draw – 115-230 VAC/50-60Hz
Dimensions
Width: 19” (482 mm)
Height: 3-1/2” (89 mm) – without feet
Depth: 13-5/8” (346 mm)
Finish
Black anodized aluminum
Product Weight
31.3 lbs. (14.2 kg)
Shipping Weight
32.5 lbs. (14.7 kg)
Included Accessories
Removable power cord
Removable rack ears
IR remote control
