Stingray Outdoor Speakers
Available in Black or White with
Paint and Custom Graphic Options
Invisible Under Eaves Soffit Kit Speakers
Invisible Impervious Speakers
StingRay speakers are known for raising the bar in outdoor audio durability and sound quality. StingRay outdoor speakers deliver smooth mid and high-frequency response with a solid, rich bass extension and are ideal for luxury residential, commercial, and marine applications.
StingRay speakers combine direct coupled motor technology with an acoustic lever technology driven by a traditional woofer to energize the entire FidelityGlass™ active surface of the speaker panel resulting in crisp highs and impactful bass.
The sleek design and versatile mounting options mean the speakers won’t be an eyesore. To further enhance the aesthetic, Stealth offers custom finishing options so your speakers can Blend In! or Stand Out!
Watch the Video
Specifications
| StingRay 6 | StingRay 8 & Soffit Kit | StingRay 83 & Soffit Kit | StingRay 430 | |
|---|---|---|---|---|
| Type | 2-way Full Range | 2-way Full Range | 3-way Full Range | Subwoofer |
| Frequency Response | 50Hz to 18kHz | 45hz to 18khz | 40hz to 20khz | 20Hz to 160Hz |
| Power Capacity | 120 watts RMS | 160 watts RMS | 160 watts RMS | 400 watts RMS |
| Recommended Power | 60 watts (Min) | 80 watts (Min) | 80 watts (Min) | 100 watts (Min) |
| Protection | 2 independent self-resetting devices (LF and HF) | 2 independent self-resetting devices (LF and HF) | 3 independent self-resetting devices (LF, MF, and HF) | 4 independent self-resetting devices (LF and HF each channel) |
| Sensitivity | 83 dB | 83 dB | 83 dB | 86 dB |
| System Impedance | 8Ω nominal | 8Ω nominal | 8Ω nominal | 8Ω nominal |
| Polar Dispersion | 170 degrees horizontal & vertical | 170 degrees horizontal & vertical | 170 degrees horizontal & vertical | 360 degrees horizontal & vertical |
| HF Driver | One 1-1/8” (30 mm) neodymium motor | One 1-1/8” (30 mm) neodymium motor | One 1” (25 mm) neodymium motor | |
| MF Driver | One 1-1/8” (30 mm) neodymium motor | |||
| LF Driver | One 1″ (25 mm) voice coil, 6.5″ (165 mm) woofer Ceramic 15 oz. (425 gr) magnet | One 1-1/2″ (38 mm) voice coil, 8″ (203 mm) woofer Ceramic 20 oz. (567 gr) magnet | One 1-1/2″ (38 mm) voice coil, 8″ (203 mm) woofer Ceramic 20 oz. (567 gr) magnet | Eight 1-1/2″ (38 mm) voice coil, 8″ (203 mm) woofer Ceramic 20 oz. (567 gr) magnet |
| Crossover | Passive 2-way | Passive 2-way | Passive 3-way | Requires amplifier with low pass filter. 50Hz with 18 dB slope recommended |
| StingRay 6 | StingRay 8 | StingRay 8‑SK | StingRay 83 | StingRay 83‑SK | StingRay 430 | |
|---|---|---|---|---|---|---|
| Width | 14-7/8” (378 mm) | 20-7/8” (530 mm) | 20-7/8” (530 mm) | 17-1/4” (438 mm) | ||
| Height | 10-7/8” (276 mm) | 14-3/4” (374 mm) | 14-3/4” (374 mm) | 31” (787 mm) | ||
| Depth | 3-13/16” (97 mm) | 3-7/8” (98 mm) | 3-7/8” (98 mm) | 17-1/4” (438 mm) | ||
| Weight | 12 lbs. (6 kg) – each | 15 lbs. (7 kg) each | 15 lbs. (7 kg) each | 76 lbs. (35 kg) each |
Downloads:
| StingRay Installation Instructions: |  |
| Soffit Kit Installation Instructions: | |
| Stingray Brochure: | |
